Nordson DAGE, the only X-ray company whose focus is on X-ray electronics inspection, offers the Nordson DAGE XD7600NT Ruby FP X-ray inspection system that uses the latest technology, flat panel detector to provide the first choice for high quality real time imaging in production.

The unique Nordson DAGE NT maintenance-free, sealed transmissive X-ray tube, providing 0.5 'm feature
recognition and up to 10 W of target power, together with the 2 Mpixel long lifetime CMOS flat panel detector
makes this jewel of a system the choice for high performance and high magnification real-time imaging.

The vertical system configuration, with the X-ray tube sitting below the isocentric move and tilt of the detector,
all controlled through the simple, joystick-free, point and click operation of the Nordson DAGE Image Wizard
Software provides the safe and collision-free inspection required for production applications. All these tasks can be simply and quickly automated from within the standard Nordson DAGE software without the need for programming skills. Optional upgrades include uCT.
